Product Description
The Open Cover Screw for Internal Hex Implant H2.43 is a precision-engineered component designed for secure sealing and controlled access to the implant during two-stage implantation procedures. It is specifically developed for implants featuring an internal hex connection H2.43 with 1-72 UNF internal thread, ensuring accurate fit and reliable clinical performance.
The screw features a 3 mm diameter body designed to effectively cover and protect the internal hex of the implant, while maintaining accessibility when required.
Manufactured from medical-grade titanium alloy (Ti-6Al-4V, ASTM F136), the component offers excellent biocompatibility, strength, and corrosion resistance. Its smooth external surface minimizes tissue irritation and supports optimal healing conditions.
Key Features
- Designed for internal hex implant connection H2.43
- Compatible with 1-72 UNF internal thread systems
- Body diameter: 3 mm for secure implant coverage
- Integrated 1.25 mm hex pin for easy handling
- Pin length options: 2 mm – 6 mm
- Medical-grade titanium Ti-6Al-4V (ASTM F136)
- Smooth surface for safe intraoral use
Design & Function
- The lower portion features a 1-72 UNF thread for secure fixation within the implant
- The upper section includes a hexagonal pin (1.25 mm) for insertion and removal
- The extended pin design allows controlled access and manipulation during surgical procedures
- Compatible with 1.25 mm Allen (431238) key and gingival punch (471230) instruments
Indications & Applications
The open cover screw is used to:
- Seal and protect the implant connection during healing
- Maintain access to the implant when required
- Support procedures involving soft tissue management and implant uncovering
Suitable for:
- Two-stage implantation protocols
- Sterilization & Handling
- Supplied non-sterile
- Must be sterilized in an autoclave at 135°C (274°F) before use
- Intended for single-use and professional dental application only
Advantages
- Provides secure sealing with accessible design
- Facilitates controlled implant access during procedures
- Durable and biocompatible material
- Easy handling and reliable fixation
- Supports efficient surgical workflow
Reviews
There are no reviews for this product, be the first to leave your review.
Answers & questions
No questions about this product, be the first and ask your question.
Titanium Open Cover Screw
It has the same function as a standard Cover Screw - closes the internal connection of the implant. Open Cover Screw consists of a pin with a diameter of 1.25mm in height from 2 mm to 6 mm, which is located on the cap in the center and a screw for screwing into the implant. Open Cover Screw screwed to fix the implant with a hollow key (431238). The choice of Open Cover Screw depends on the thickness and height of the gums in the area of implantation. After the wound is sutured, the protruding pin should be located in the thickness of the gum. If the pin protrudes from the gum, it should be changed to Open Cover Screw with a lower protruding pin or cut. The speaker pin gives the doctor, at the stage of disclosure of the implant; it is easy to find the location of the implant, to make disclosure of the implant using a hollow key (431238) and a punch gum (471230).
Advantage of Open Cover Screw:
- no need to make a cut;
- there is no need to exfoliate the gums;
- no need to stitch;
- minimal loss of the gum with a diameter of 3.5mm above the implant;
- perforation of the gums in the center of the implant. (As a protruding pin, is the guide for the punch);
- there is no loss of height of the gingival margin;
- prosthetics can be started on the day of disclosure.
