Product Description
The Open Cover Screw for Narrow Implant H2.1 is a precision-engineered component designed to securely seal the internal connection of narrow dental implants while allowing controlled access during the healing phase of two-stage implantation procedures. It is specifically developed for implants featuring an internal hex connection H2.1 with 1-72 UNF internal thread, ensuring accurate fit and reliable clinical performance.
The screw features a 3 mm diameter body, designed to effectively cover and protect the internal hex of the implant while maintaining accessibility when required.
Manufactured from medical-grade titanium alloy (Ti-6Al-4V, ASTM F136), the component provides excellent biocompatibility, strength, and corrosion resistance. Its smooth external surface minimizes tissue irritation and supports optimal healing conditions.
Key Features
- Designed for internal hex implant connection H2.1 (Narrow Platform)
- Compatible with 1-72 UNF internal thread systems
- Body diameter: 3 mm for secure implant coverage
- Integrated 1.25 mm hex pin for placement and retrieval
- Pin length options: 2 mm, 3 mm, 4 mm, 6 mm
- Medical-grade titanium Ti-6Al-4V (ASTM F136)
- Smooth surface for safe intraoral use
Design & Function
- The lower portion includes a 1-72 UNF thread for secure fixation within the implant
- The upper section features a hexagonal pin (1.25 mm) used for insertion and removal
- The extended pin design allows easy localization of the implant during the uncovering stage
Compatible with:
- 1.25 mm Allen key (431238)
- Gingival Punch (471230)
Indications & Applications
The open cover screw is used to:
- Seal and protect the implant connection during healing
- Maintain controlled access to the implant
- Facilitate minimally invasive implant uncovering procedures
Suitable for:
Two-stage implantation protocols
Sterilization & Handling
- Supplied non-sterile
- Must be sterilized in an autoclave at 135°C (274°F) before use
- Intended for single-use and professional dental application only
Advantages
- Provides secure sealing with accessible design
- Enables precise implant localization during exposure
- Supports minimally invasive uncovering procedures
- Durable and biocompatible material
- Easy handling and reliable fixation
Reviews
There are no reviews for this product, be the first to leave your review.
Answers & questions
No questions about this product, be the first and ask your question.
Intended Use
The Open Cover Screw H2.1 is intended for temporary placement in narrow dental implants to:
- Seal and protect the internal implant connection
- Maintain controlled access to the implant during healing
- Facilitate minimally invasive implant uncovering
Indications
- Use with implants featuring internal hex connection H2.1 (Narrow Platform)
- Suitable for two-stage implantation procedures
- Recommended when simplified implant exposure is desired
Preparation Before Use
- Supplied non-sterile
- Must be sterilized before use in an autoclave at: 135°C (274°F)
- Inspect the component for any damage or contamination prior to use
Selection Criteria
Select the appropriate pin length based on gingival thickness: available pin lengths: 2 mm, 3 mm, 4 mm, 6 mm
After suturing:
- The pin should be positioned within the gingival tissue
- If the pin protrudes excessively: replace with a shorter version or adjust according to clinical requirements
Clinical Procedure
- Ensure the implant is properly placed and stable
- Clean and dry the internal implant connection
- Insert the Open Cover Screw into the implant
- Tighten using 1.25 mm Allen key (431238)
- Suture the surgical site, ensuring correct positioning of the pin
- Allow healing according to standard clinical protocol
Implant Uncovering
At the stage of implant exposure:
The protruding pin serves as a guide for locating the implant
Use:
- Allen key (431238) for removal
- Gingival Punch (471230) for soft tissue access
This allows precise and minimally invasive uncovering of the implant.
Post-Placement Care
- Monitor healing of surrounding soft tissue
- Maintain proper oral hygiene
- Follow standard clinical protocols during the healing phase
Removal
- Remove the Open Cover Screw using 1.25 mm Allen key (431238)
- Proceed with placement of healing abutment or prosthetic components
Warnings & Precautions
- For professional dental use only
- Single-patient use recommended
- Do not reuse if damaged or contaminated
- Ensure compatibility with H2.1 implant systems
- Avoid excessive protrusion of the pin above gingival tissue
- Follow standard implantology protocols
Storage
- Store in a clean, dry environment
- Avoid contamination prior to sterilization
