Product Description
Titanium Esthetic Screw Abutment Connector Short System H2.43
The Titanium Esthetic Screw Abutment Connector Short System H2.43 is a precision prosthetic component designed for screw-retained implant restorations on short implant systems with H2.43 internal connection.
The abutment features a straight 0° angulation relative to the implant axis, providing accurate prosthetic positioning and stable restorative support for implant-supported rehabilitations. The component connects directly to the implant by screwing into the internal thread of the implant.
Manufactured from medical-grade titanium alloy Ti6Al4V ASTM F136, the abutment provides excellent mechanical strength, biocompatibility, corrosion resistance, and long-term dimensional stability for implant prosthetic applications.
The component is intended for use with titanium prosthetic screw M2 (Ref. 701200) for fixation of permanent screw-retained restorations.
Key Features
- Straight abutment design with 0° angulation
- Designed for screw-retained restorations
- Direct connection to short implant systems H2.43
- Precision-machined titanium construction
- Compatible with titanium prosthetic screw M2 (701200)
- Stable prosthetic support for implant restorations
- Compatible with 1.25 mm hex driver
- Designed for short implant restorative workflows
Available Versions / References
- Titanium prosthetic screw M2: 701200
- Implant connection: H2.43 internal connection
Compatible Implant Systems
Short UNIQUE Implant:
- Lengths: 5 mm, 6 mm, 7 mm
- Diameters: 3.75 mm, 4.2 mm, 5.0 mm, 6.0 mm
Short PRIMA Implant:
- Lengths: 5 mm, 6 mm, 7 mm
- Diameters: 3.75 mm, 4.2 mm, 5.0 mm, 6.0 mm
Technical Specifications
- Shoulder diameter: 4.7 mm
- Angulation: 0°
- Hex connection: 1.25 mm
Material
Manufactured from medical-grade titanium alloy Ti6Al4V ASTM F136, providing:
- High mechanical strength
- Excellent biocompatibility
- Corrosion resistance
- Precision and long-term durability
- Reliability for implant prosthetic restorations
Clinical / Laboratory Application
- Screw-retained implant restorations
- Implant-supported prosthetic rehabilitation
- Restorative procedures on short implant systems
- Permanent prosthetic structure fixation
- Implant-supported permanent restorations
Sterilization
Before clinical use, the product must be sterilized in an autoclave at 135°C / 274°F.
Advantages
- Stable connection to short implant systems
- Reliable support for screw-retained restorations
- Straight prosthetic alignment
- Durable and biocompatible titanium construction
- Compatible with multiple short implant platforms
- Supports accurate and predictable prosthetic outcomes
Reviews
There are no reviews for this product, be the first to leave your review.
Answers & questions
No questions about this product, be the first and ask your question.
Titanium Esthetic Screw Abutment Connector Short System H2.43
Intended Use
The Titanium Esthetic Screw Abutment Connector is intended for:
- Screw-retained implant-supported restorations
- Prosthetic rehabilitation on short implant systems
- Implant-supported permanent restorations
- Prosthetic fixation on osseointegrated implants
Indications
The product is indicated for use with:
- Short UNIQUE Implant systems
- Short PRIMA Implant systems
- Implants with H2.43 internal connection
- Screw-retained prosthetic restorations
- Titanium prosthetic screw M2 (701200)
Contraindications
Do not use the product in:
- Patients with known hypersensitivity to titanium alloys
- Clinical situations incompatible with implant-supported restorations
- Cases where the component is damaged, deformed, or worn
Warnings
- Product is supplied non-sterile.
- Sterilization before clinical use is mandatory.
- Use only compatible implant systems, prosthetic components, and fixation screws.
- Improper seating may result in prosthetic misfit or mechanical complications.
- Do not use excessive tightening force.
- Intended for professional dental use only.
Precautions
- Verify compatibility with the implant system before use.
- Inspect the component before clinical application.
- Ensure complete seating of the abutment into the implant connection.
- Use only compatible titanium prosthetic screw M2 (701200).
- Use only a 1.25 mm hex driver.
- Follow standard implant prosthetic and infection control procedures.
Instructions for Clinical Use
1. Preparation
- Verify implant compatibility and prosthetic treatment plan.
- Clean and dry the implant connection area before placement.
2. Placement of the Abutment
- Position the Titanium Esthetic Screw Abutment Connector into the implant internal connection.
- Secure the abutment by screwing into the internal thread of the implant.
- Tighten using a 1.25 mm hex driver according to standard prosthetic protocols.
3. Prosthetic Procedure
- Attach the permanent prosthetic restoration.
- Secure the restoration using titanium prosthetic screw M2 (701200).
- Verify passive fit and prosthetic alignment before final fixation.
4. Final Restoration
- Complete the screw-retained restorative procedure according to standard clinical protocols.
- Verify occlusion, prosthetic stability, and final seating.
Cleaning and Sterilization
- Sterilization Parameters
- Autoclave sterilization
- Temperature: 135°C / 274°F
Storage
- Store in a clean, dry environment.
- Protect from contamination, moisture, and mechanical damage.
- Avoid exposure to corrosive substances.
