Product Description
Scan Body Transfer for Multi-Unit 1-72 UNF
The Scan Body Transfer for Multi-Unit 1-72 UNF is a high-precision component designed to accurately transfer implant position and orientation into digital workflows. Engineered for compatibility with multi-unit abutment systems utilizing 1-72 UNF screw connections, it ensures reliable and consistent data acquisition for CAD/CAM prosthetic fabrication.
Its optimized geometry and surface characteristics enable precise recognition by intraoral and laboratory scanners, allowing for accurate digital impressions and seamless integration into modern digital dentistry workflows. The scan body provides a stable and secure fit when used with the appropriate fixation screw, minimizing movement during scanning and enhancing overall accuracy.
Manufactured from high-quality materials, the component offers excellent durability, dimensional stability, and resistance to wear, making it suitable for repeated clinical and laboratory use.
Key Features
Designed for digital scanning and CAD/CAM workflows
Compatible with multi-unit systems using 1-72 UNF screw connection
High-precision geometry for accurate scan data capture
Secure fixation with screw for enhanced stability
Optimized surface for reliable scanner detection
Durable and wear-resistant construction
Indications & Applications
The Scan Body Transfer is intended for:
- Digital impression-taking using intraoral or laboratory scanners
- Transfer of implant position into CAD/CAM software
- Fabrication of implant-supported restorations
- Single and full-arch prosthetic cases
Clinical Benefits
- Accurate digital transfer of implant position
- Improved precision in prosthetic design and fabrication
- Reduced risk of errors compared to conventional impressions
- Streamlined and efficient digital workflow
Sterilization & Handling
- Supplied non-sterile
- Must be cleaned and sterilized before use
- Compatible with standard steam sterilization protocols (autoclave)
Advantages
- High accuracy and reproducibility
- Easy placement and removal
- Reliable performance in digital workflows
- Optimized for multi-unit implant restorations
Reviews
There are no reviews for this product, be the first to leave your review.
Answers & questions
No questions about this product, be the first and ask your question.
Scan Body Transfer for Multi-Unit 1-72 UNF
Indications for Use:
- For digital impression-taking of implants
- For use with multi-unit abutment systems with 1-72 UNF screw connection
- For CAD/CAM prosthetic workflows
- Suitable for single and multi-unit restorations
Contraindications:
- Not intended for use in patients with known allergies to the material
- Do not use with incompatible implant systems
Warnings:
- For use by qualified dental professionals only
- Improper use may result in inaccurate digital impressions and prosthetic misfit
- Ensure correct fixation before scanning
Precautions:
- Ensure the component is clean and sterile before use
- Use the appropriate fixation screw for secure placement
- Avoid contamination during clinical procedures
- Handle with care to prevent damage or deformation
- Do not apply excessive force during placement or removal
Instructions for Use:
- Verify compatibility with the multi-unit system (1-72 UNF connection).
- Clean and sterilize the scan body prior to use.
- Place the scan body onto the multi-unit abutment.
- Secure the scan body using the appropriate fixation screw.
- Ensure it is fully seated and stable.
- Perform digital scanning using an intraoral or laboratory scanner.
- Remove the scan body after scanning is completed.
- Proceed with digital design and prosthetic fabrication.
Cleaning and Sterilization:
- Supplied non-sterile
- Clean using manual or ultrasonic cleaning methods
- Sterilize using standard steam sterilization (autoclave at 134°C)
Storage:
- Store in a clean, dry environment
- Keep in original packaging until use
